| Total Time Since New | 3,257 Hours (As of July 2021) |
| Total Landings Since New | 2,213 Landings |
| Entry into Service Date | April 2, 2007 |
| Home Base | Portugal |
| Maintenance Tracking | CAMP |
| Certification | EU OPS1 |
| Left Engine | Right Engine | |
| Description | Williams International FJ44-3A | |
| Serial Number(s) | 141301 | 141300 |
| Total Hours Since New | 3,218 Hours | 3,244 Hours |
| Total Cycles Since New | 2,185 Landings | 2,204 Landings |
| Program Coverage | TAP Advantage Blue | |
The Cessna Citation CJ3 is equipped with an integrated, Pro Line 21 avionics suite. A general summary of this aircraft’s avionics suite is as follows:
| Type of Unit | Quantity | Unit Description | ||
| EFIS (Electronic Flight Instrument System) | 3-tube | ADF-3010 PFD and MFD | ||
| FMS (Flight Management System) | Dual | Rockwell Collins FMS-3000 | ||
| ADC (Air Data Computer) | Dual | Collins Aerospace ADC-3000 | ||
| GPS (Global Positioning System) | Dual | GPS-4000A | ||
| ECU (Engine Control Unit) | Single | Dual Channel FADEC | ||
| NAV (Navigation Radio) | Dual | Collins NAV-4000 | ||
| DME (Distance Measuring Equipment) | Single | Collins DME-4000 | ||
| ADF (Automatic Direction Finder) | Dual | Collins NAV-4000 | ||
| A/P (Autopilot) | Single | Collins | ||
| VHF COM (Very High Freq. Communication) | Dual | Collins Aerospace VHF-4000 | ||
| HF COM (High Frequency Communication) | Single | Collins HF-9031A | ||
| AFIS (Airborne Flight Information System) | Single | Datalink XMWR-1000 | ||
| RADAR | Single | Rockwell Collins RTA-800 | ||
| RAD ALT (Radio Altimeter) | Single | Rockwell Collins ALT-4000 | ||
| XPNDR (Transponder) | Dual | Rockwell Collins TDR-94D w/ 8.33kHz Spacing | ||
| EGPWS (Enhanced Ground Proximity Warning System) | Single | Honeywell Mark VIII | ||
| TCAS (Traffic Collision Avoidance System) | Single | Collins TTR-4000 w/ Change 7.1 | ||
| CVR (Cockpit Voice Recorder) | Single | CVR L3 Harris FA2100 | ||
| FDR (Flight Data Recorder) | Single | FDR L3 Harris FA2100 | ||
| ELT (Emergency Locator Transmitter) | Single | Artex C406-N | ||
| Description | |
| Number of Passengers | Six Passengers + Belted Lav |
| Refreshment Centre | Yes |
| Forward Cabin Configuration | Four (4) Club Seats w/ Fold Out Tables |
| Aft Cabin Configuration | 2 Single Forward-Facing Seats w/ Single Foldable Table |
| Lavatory Location(s) | Aft |
| Last Refurbishment Date | Original |
| Base Paint Color(s) | White |
| Stripe Color(s) | Black and Grey |
| Last Painted Date | Original |
Click here to view the online range map. To receive a more detailed custom range report including detailed aircraft comparisons, contact us at +1 919 941 8400 or [email protected].
| Inspection | Last Performed | Next Due |
| 12 Month (Inspection Doc 5) | September 2022 | September 2023 |
| 24 Month (Inspection Doc 6) | September 2022 | September 2024 |
| 36 Month (Inspection Doc 22) | September 2022 | September 2025 |
| 48 Month (Inspection Doc 8) | February 2019 | February 2023 |
| 72 Month (Inspection Doc 9) | February 2019 | February 2025 |
| RVSM |
| TCAS 7.1 |
| ADS-B Out |
