Total Time Since New | 2,228 Hours (as of May 2, 2022) |
Total Landings Since New | 1,874 Landings |
Certification Date | September 2013 |
Home Base | St. Paul, MN (KSTP) |
Program Coverage | Embraer Executive Care Standard – EEC |
Certification | FAA Part 91 |
Left Engine | Right Engine | ||
Description | Pratt & Whitney PW535E | ||
Serial Number | PCE-DG0258 | PCE-DG0259 | |
Total Hours Since New | 2,228 Hours | 2,228 Hours | |
Total Cycles Since New | 1,874 Cycles | 1,874 Cycles | |
Program Coverage | Pratt & Whitney ESP Gold Lite – Deferred (Current Program) | ||
Pratt & Whitney ESP Gold Lite, Gold and Platinum (Coverages Available) |
The Embraer Phenom 300 is equipped with an integrated, Garmin G1000 Prodigy avionics suite. A general summary of this aircraft’s avionics suite is as follows:
Type of Unit | Quantity | Unit Description |
EFIS (Electronic Flight Instrument System) | Triple | Garmin GDU 1240A |
GPS (Global Positioning System) | Dual | Garmin GIA 63W |
NAV (Navigation Radio) | Dual | Garmin GIA 63W |
DME (Distance Measuring Equipment) | Single | Bendix King KN63 |
ADF (Automatic Direction Finder | Single | Collins ADF 462 |
AHRS (Attitude and Heading Reference System) | Dual | Garmin GRS 77 |
VHF COM (Very High Freq. Communications) | Dual | Garmin GIA 63W |
HF COM (High Freq. Communications) | Single | Bendix King KRX 1053 |
SATCOM (Satellite Communications) | Single | Garmin GSR 56 |
WRADAR (Weather Radar) | Single | Garmin GWX 68 |
SATWX (Satellite Weather) | Single | Garmin GDL 69A |
RADAR ALT (Radar Altimeter) | Single | Honeywell KRA 405B |
XPNDR (Transponder) | Single | L3 Harris NXT-600 |
TCAS (Traffic Collision Avoidance System) | Single | L3 Harris TCAS 3000SP |
CVR (Cockpit Voice Recorder) | Single | L3 Harris FA 5000 |
FDR (Flight Data Recorder) | Single | L3 Harris FA 2100 |
ELT (Emergency Locator Transmitter) | Single | Kannad 406AF |
Number of Passengers | Seven (7) Passenger + One (1) Belted Lavatory |
Galley Location | Forward Refreshment Center |
Refreshment Center | Forward RH |
Forward Cabin Configuration | One (1) Aft Facing Seat |
Mid Cabin Configuration | Four (4) Place Club Seats |
Aft Cabin Configuration | Two (2) Forward Facing Seats |
Lavatory Location(s) | Aft Belted Lavatory |
Last Refurbished Date | Original Completion |
Base Paint Color(s) | Matterhorn White |
Stripe Color(s) | Green, Orange and Light Blue |
Last Painted Date | Original Completion |
Click here to view the online range map. To receive a more detailed custom range report including detailed aircraft comparisons, contact us at +1 919 941 8400 or [email protected].
Inspection | Last Performed | Next Due |
12 Month | October 2021 | September 2022 |
24 Month | October 2021 | September 2023 |
48 Month | October 2021 | September 2025 |
60 Month | December 2018 | September 2023 |
120 Month | September 2013 | September 2023 |
